无框架永磁无刷电机EWM-04925-A
技术参数
商品型号
EWM-04925-A
母线电压Vdc
28
最高转速(空载)rpm
2470
额定转速rpm
1685
额定转矩N.m
0.27
额定功率W
47.8
额定点相绕组电流Arms
2.34
额定点发热功率W
11.3
连续堵转转矩N.m
0.387
连续堵转点相绕组电流Arms
3.36
连续堵转点发热功率W
20.9
峰值堵转转矩N.m
1.57
峰值堵转点相绕组电流Arms
14.74
峰值堵转点发热功率W
333
转矩系数N.m/Arms
0.115
反电势系数 Vpk/krpm
10.77
绕组线电阻Ω
1.28
绕组线电感mH
1.875
直轴电感mH
0.703
交轴电感 mH
0.703
转子转动惯量 Kg.m2
1.04×10-5
重量 Kg
0.27
极数
10
